⚡สินค้าแต่ละล็อต รูปแบบ และสีของตัวอักษรอาจแตกต่างกัน ให้ดูที่เบอร์(IR2010S)เป็นหลัก⚡
Product: IGBT, MOSFET Gate Drivers
Type: High Side, Low Side
Mounting Style: SMD/SMT
Package / Case: SOIC-16
Number of Drivers: 2 Driver
Number of Outputs: 2 Output
Output Current: 3 A
Supply Voltage - Min: 10 V
Supply Voltage - Max: 20 V
Configuration: High Side, Low Side
Rise Time: 20 ns
Fall Time: 25 ns
Minimum Operating Temperature: - 25 C
Maximum Operating Temperature: + 125 C
Series: IR(S)201X
Packaging: Tube
Height: 2.35 mm
Length: 10.5 mm
Technology: Si
Width: 7.6 mm
Brand: Infineon / IR
Logic Type: CMOS, LSTTL
Propagation Delay - Max: 135 ns
Shutdown: Shutdown
Maximum Turn-Off Delay Time: 65 ns
Maximum Turn-On Delay Time: 95 ns
Moisture Sensitive: Yes
Operating Supply Current: 230 uA
Operating Supply Voltage: 10 V to 20 V
Pd - Power Dissipation: 1.25 W
