Model Parameters
Model X5S-4W X5S-8W
IPC access capability
Wireless IPC access capability 5MP *4 5MP *8
Wired IPC access capability 5MP *4 5MP *8
Network Parameter
Antenna Number 2 2
Maximum wireless Range 100m 100m
Radio frequency 2.4G 2.4G
Ethernet Port one 10/100M adaptable ethernet interface one 10/100M adaptable ethernet interface
Required access bandwidth 50mbps 100mbps
Video Output
VGA 1 channel (identical to HDMI output) resolution up to: 1920*1080/60Hz 1 channel (identical to HDMI output) resolution up to: 1920*1080/60Hz
HDMI 1 Channel resolution up to: 2560*1440/30HZ 1 Channel resolution up to: 2560*1440/30HZ
Audio/Video Codec
Recording resolution 5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/2CIF/CIF/QCIF 5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/2CIF/CIF/QCIF
Video compression H.265, H.264 H.265, H.264
Decode playback Support 4*5MP Support 8*5MP
Video Recording Management
Video recording mode Manual video recording; Motion detecton recording; Scheduled video recording; Event triggered recording Manual video recording; Motion detecton recording; Scheduled video recording; Event triggered recording
Video recording mode Hard disk backup, Internet applicaton backup Hard disk backup, Internet applicaton backup
playback mode Instant playback; Normal playback; Event playback; Tag playback; Log event playback Instant playback; Normal playback; Event playback; Tag playback; Log event playback
Open protocol
Open protocol support HIKVISION, ONVIF(V2.5) HIKVISION, ONVIF(V2.5)
HDD
Interface type One built-in SATA port One built-in SATA port
Capability Supports 1TB to 8TB 3.5inch HDD Supports 1TB to 8TB 3.5inch HDD
External Interface
Audio output Not support Not support
Audio intput Not support Not support
Hardware reset Supports Supports
USB2.0 interface 1 1
Dimensions (mm)
Product dimensions 235mm x 270mm x 44.5 mm 235mm x 270mm x 44.5 mm
Packaging dimensions 387mm x 362mm x 75mm 387mm x 362mm x 75mm
Weight
Net Weight =900g =900g
