Main
Range of product : AvatarOn A
Product or component type : Socket-outlet
Device presentation : Complete product
Colour tint : Grey
Outlet poles configuration : 2P + E
Colour tint : Grey
Complementary
Rated current : 16 A at 250 V AC 50...60 Hz
Socket number : 1
Clamping connection capacity
2 x 1.5...2 x 4 mm² for solid cable(s)
2 x 1.5...2 x 4 mm² for stranded cable(s)
Connections - terminals : Screwless terminals
Material
Polycarbonate grid plate
Polycarbonate cover
Device mounting : Flush
Width : 120 mm
Height : 70 mm
Depth : 30.3 mm
Embedding depth : 19 mm
Environment
IP degree of protection : IP20
Maximum ambient air temperature for operation : 35 °C
Ambient air temperature for storage : -5…45 °C
Relative humidity : 0…95 %
Operating altitude : < 2000 m
Standards : IEC 60884-1
Product certifications : IEC
