Main
Range of product : AvatarOn A
Product or component type : USB charger
Mounting mode : Flush-mounted
Integrated connection type : 2 USB port 5 V AC/DC, maximum load current: 2.4 A
Complementary
Device presentation : Complete product
Colour tint : Black
Surface finish : Matt
Surface treatment : Painted
Ambient air temperature for operation : -5…45 °C
Ambient air temperature for storage : -5…60 °C
Relative humidity : 0…95 %
[Ue] rated operational voltage : 110...220 V 50...60 Hz
Input power : 12 W
maximum load current with 2 outputs used simultaneously : 2.4 A
Material : PC (UL94 V-0)
Screwdriver shape : Philips No 2
Clamping connection capacity : 0.5...4 mm² for solid or flexible cable(s)
Wire stripping length : 12 mm
Height : 69.3 mm
Width : 46.6 mm
Depth : 36 mm
Embedding depth : 25 mm
Material : PC (UL94 V-0)
Screwdriver shape : Philips No 2
Clamping connection capacity : 0.5...4 mm² for solid or flexible cable(s)
Wire stripping length : 12 mm
Height : 69.3 mm
Width : 46.6 mm
Depth : 36 mm
Embedding depth : 25 mm
Environment
Standards : IEC 62368-1
Product certifications : IEC
IP degree of protection : IP20
