Battery Backup & Surge Protector for Electronics and Computers
Includes: User manual
Output
Output power capacity : 410 Watts / 750VA
Max Configurable Power (Watts) : 410 Watts / 750VA
Nominal Output Voltage : 230V
Output Frequency (sync to mains) : 50/60 Hz +/- 1 Hz Sync to mains
Topology : Line interactive
Waveform type : Stepped approximation to a sinewave
Output Connections : (1) IEC 60320 C13
Transfer Time : 6 ms typical : 10 ms maximum
Input
Nominal Input Voltage : 230V
Input frequency : 50/60 Hz +/- 5 Hz Auto-sensing
Input Connections : IEC 60320 C14
Cord Length : 1.2meters
Input voltage range for main operations : 140 - 300V
Number of Power Cords : 1
Input Power Factor at Full Load : 0.63
Batteries & Runtime
Replacement Battery : www.apc.com/shop/uk/en/products/APC-Replacement-Battery-Cartridge-17/P-RBC17
Expected Battery Life (years) : 3 - 5
Runtime : View Runtime Graph (Available in Technical Tab on site)
View Runtime Chart (Available in Technical Tab on site)
Efficiency : View Efficiency Graph (Available in Technical Tab on site)
Communications & Management
Control panel : LED Status display with on line : on battery
Audible Alarm : Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering
Surge energy rating : 273Joules
Data Line Protection : RJ45 10/100/1000 Base-T Ethernet protection
Physical
Maximum Height : 160MM, 16.0CM
Maximum Width : 120MM, 12.0CM
Maximum Depth : 355MM, 35.5CM
Net Weight : 5.4KG
Shipping weight : 5.9KG
Shipping Height : 250MM, 25.0CM
Shipping Width : 197MM, 19.7CM
Shipping Depth : 430MM, 43.0CM
Color : Black
Environmental
Operating Temperature : 0 - 40 °C
Operating Relative Humidity : 0 - 95 (Non-condensing) %
Operating Elevation : 0 - 3000meters
Storage Temperature : -15 - 40 °C
Storage Relative Humidity : 0 - 95 (Non-condensing) %
Storage Elevation : 0 - 3000meters
Audible noise at 1 meter from surface of unit : 40.0dBA
Protection Class : IP20
