Electrical connection : Copper busbar connection
[In] rated current : 100 A
[Ue] rated operational voltage : 240 V
Network frequency : 50/60 Hz
Short-circuit current : 10 kA
Options for Protection device type
QO type miniature circuit breaker (MCB) - 2P in main incomer
QO type miniature circuit breaker (MCB) - 1P in outgoer
QO type residual current circuit breaker with overcurrent protection (RCBO) - 1P - 10 mA in outgoer
QO type residual current circuit breaker with overcurrent protection (RCBO) - 1P - 30 mA in outgoer
QO type residual current circuit breaker with overcurrent protection (RCBO) - 2P in main incomer
QO type surge protection device (SPD) in outgoer
Type of front cover : Steel with cut-out
Door type : Transparent dolly cover - plastic
Door opening side : Upwards
Cable entry
knock-out at top and bottom
knock-out at rear
knock-out at both side
Enclosure material : Phosphated cold rolled steel of 1.2 mm thickness
Surface treatment : Epoxy
Colour : White (RAL 9003)
Height : External: 206 mm
Width : External: 391 mm
Depth : External : 102 mm
Environment
Standards
TIS 1436-2540
IEC 61439-3
IP degree of protection : IP4X
Product certifications
ASTA conforming to IEC 61439-3
TIS conforming to TIS 1436-2540
