รายละเอียดสินค้าจากร้านค้า
คุณสมบัติ
Brand TP-LINK
Model EAP225-Outdoor
Standards and Protocol IEEE 802.11a/b/g/n/ac
Antenna 2 Dual-Band Omni Antennas
2.4GHz : 2 x 3dBi
5GHz : 2 x 4dBi
Beamforming
Frequency Range 2.4GHz, 5GHz
Wireless Transmit Power CE : <20dBm(2.4GHz,EIRP),<23dBm(5GHz,EIRP)
FCC : <30dBm(2.4GHz, EIRP),<30dBm(5GHz, EIRP)
Interface 1 x Gigabit Ethernet (RJ-45)Port*1(Support 802.3af PoE and Passive PoE)
Button Reset
Data Rates 802.11ac:
- 5G:6.5 Mbps to 867Mbps(MCS0-MCS9,NSS = 1 to 2 VHT20/40/80)
- 2.4G:78Mbps to 300Mbps (MCS8-MCS9 VHT20/40, NSS=1 to 3)
802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 5.5, 11Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Management / Configuration / Tools Omada Controller Software
Email Alerts
Management MAC Access Control
System Logging Local/Remote Syslog
Web-based Management
L3 Management
Multi-site Management
Management VLAN
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
Wireless Features Multiple SSIDs（Up to 16 SSIDs, 8 for each band）
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control （Adjust Transmit Power on dBm）
QoS(WMM)
MU-MIMO
Airtime Fairness
Beamforming
Band Steering
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
PoE 802.3af PoE and 24 Passive PoE(PoE Adapter Included)
Wall/Ceiling Mount Pole/Wall Mounting (Kits included)
Power Consumption 10.5W
Ingress Protection IP 65
Environment Operating Temperature: -30°C~70°C (-22°F~158°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Dimensions 8.5 x 1.8 x 1.1in. (215 x 46 x 27 mm)
Certifications CE, FCC, RoHS
Package Contents AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point
EAP225-Outdoor
Power Adapter
Mounting Kits
Installation Guide
