APC Easy- UPS 500VA, AVR, Universal Outlet, 230V Warranty 2-Years by APC

เสียบฟิวส์สีเหลืองด้านหลังเครื่องก่อนใช้งาน

Technical Specifications

Output

Output power capacity

300Watts / 500VA

Max Configurable Power (Watts)

300Watts / 500VA

Nominal Output Voltage

230V

Output Frequency (not synced)

50/60 Hz +/-1 Hz

Topology

Line Interactive

Waveform type

Stepped approximation to a sinewave

Transfer Time

6ms typical : 10ms maximum

Input

Nominal Input Voltage

230V

Input frequency

50/60 Hz +/- 5 Hz (auto sensing)

Input Connections

IEC-320 C14

Cord Length

1.52meters

Number of Power Cords

1

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Expected Battery Life (years)

3-5

Efficiency

View Efficiency Graph

Communications & Management

Control panel

LED Status display with On Line : On Battery

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Physical

Maximum Height

92MM, 9.25CM

Maximum Width

160MM, 16.05CM

Maximum Depth

305MM, 30.5CM

Net Weight

3.9KG

Shipping weight

4.2KG

Shipping Height

237MM, 23.7CM

Shipping Width

143MM, 14.3CM

Shipping Depth

373MM, 37.3CM

SCC Codes

1073130433829 8

Environmental

Operating Temperature

0 - 40 °C

Operating Relative Humidity

0 - 90 %

Operating Elevation

0-1968.3meters

Audible noise at 1 meter from surface of unit

40.0dBA

Conformance

Approvals

CE

Sustainable Offer Status

RoHS

Compliant

REACH

REACH: Contains No SVHCs
