Product Information
Product Type
Product Type
Ceiling AP
Hardware Specifications
Wi-Fi Radio
Radio design
Dual-radio
4 spatial streams
● 2.4 GHz: 2 x 2, MU-MIMO
● 5 GHz: 2 x 2, MU-MIMO
Maximum wireless data rate
1774 Mbps
6 GHz wireless data rate
No
5 GHz wireless data rate
1201 Mbps
2.4 GHz wireless data rate
573 Mbps
Antenna
Antenna
2.4 GHz: 2 built-in omnidirectional antennas
5 GHz: 2 built-in omnidirectional antennas
Dimensions and Weight
Product dimensions (W x D x H)
194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket)
Color
White
Weight
≤ 0.55 kg (1.21 lbs.) (without packaging materials)
Port Specifications
Number of 10/100/1000BASE-T ports
2
Power Supply and Consumption
Power supply
● DC power adapter
● PoE/PoE+
Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
Local power supply
Yes, one DC power connector (12 V, 1.5 A)
Dimensions of the DC connector
Outer diameter: 5.5 mm (0.22 in.)
Inner diameter: 2.1 mm (0.08 in.)
Depth: 10 mm (0.39 in.)
PoE budget
No
Maximum power consumption
15.5 W
Environment and Reliability
Operating temperature
0°C to 40°C (32°F to 104°F)
Mounting options
Ceiling/Wall
IP rating
IP41
Software Specifications
WLAN
Maximum number of associated wireless clients
64 (2.4 GHz)
256 (5 GHz)
256 (2.4 GHz and 5 GHz enabled)
Maximum number of devices that can be managed
300
IP Service
IPv6
Yes
Order Information
Mounting Bracket
1
Cross Pan Head Screw 2
Expansion Anchor 2
Quick Start Guide 1
Warranty Card 1
Package Weight 0.83kg
Package Dimension (w x d x h) 222 mm x 220 mm x 68 mm
