⭐⭐Input Data (DC, PV)
Max Solar Panel Input Power: 2*500W
MPPT Voltage Range: 33V-54V
Startup Voltage: >22V d.c.
Maximum input Current: 2*18A
Maximum Input Short Circuit Current: 2*20A
Maximum Feedback Current Of The Array: 0A
⭐⭐Output Data(AC)
Single-Phase Grid Type: 120V&230V
Rated Output Power: 800W
Maximum Output Power: 800W
Rated Output Current: @120V:6.6A / @230V:3.5A
Nominal Output Voltage Range: @120V a.c. / @230V a.c.
Nominal Frequency Range: 50Hz / 60Hz
Default Output Frequency Range: @50Hz:48Hz-51Hz / @60Hz:58Hz-61Hz
Power Factor: >0.99%
Harmonic Distortion Of Output Current: <5%
Maximum Number Of Connections Per Branch: @120V:6Pcs / @230V:12Pcs
⭐⭐Efficiency
Peak Microinverter Efficiency: 92.7%
Nominal MPPT Efficiency: 99.8%
Night power consumption(mW): 0
⭐⭐Mechanical Data
Ambient Temperature Range: -20℃ to +50℃
Storage Temperature Range: -20°C to +50℃
Dimensions(L*W *H): 280mm*200mm*48.5mm
Weight: 1.65kg
Waterproof level: IP65
Cooling method: Natural cooling (no fan)
Degree of pollution: PD3
⭐⭐Other Features
Power Delivery Mode: Reverse transmission, load priority
Communication: WIFI
Rated transmit power: 802.11b:+17dBm+1.5dBm(@11Mbps) / 802.11g:+15dBm+1.5dBm(@54Mbps) / 802.11n:+14dBm+1.5dBm(@HT20,MCS7)
Surveillance system: Smart Life
Bluetooth:2402-2480MHz Bluetooth EIRP Power(Max.)7.89dBm
Wifi 2.4G: 2412-2472MHz Wifi2.4G EIRP Power(Max.)18.08dBm
