● เครื่องสำรองไฟขนาดเริ่มต้น สำหรับ Computer PC 1 ชุด สำรองไฟได้ 2-3 นาที
Specifications
Overview
● Lead time : Usually in Stock
Main
● Main Input Voltage : 220...240 V AC 1 phase
● Main Output Voltage : 230 V
● Rated power in W : 375 W
● Rated power in VA : 900 VA
● Product or component type : Uninterruptible power supply (UPS)
● Input Connection Type : NEMA 4.1 A
● Output connector type : Universal
● Battery type : VRLA
● Range of product : Easy UPS
Batteries & Runtime
● Number of battery replacement quantity : 0
● Battery charger power : 14 W indoor use only
● Battery design life : 3…5 year(s)
● Battery life : 3…5 year(s)
● Extended runtime : 0
General
● Max runtime : 0.01 min
Physical
● Colour : Black
● Height : 142 mm
● Width : 101 mm
● Depth : 300 mm
● Net weight : 4.9 kg
Input
● Network frequency : 50/60 Hz +/- 5 Hz indoor use only
● Input protection type : Circuit breaker
Output
● Maximum configurable power in W : 375 W
● UPS type : Line interactive
● Wave type : Stepped approximation to a sinewave
● Output voltage tolerance : +/- 10 %
● Full load runtime : 00:00:01 480 W
● Graph display :1
● Graph start point : 10
● Half load runtime : 00:02:24 240 W
● Transfer time : 6 ms typical : 10 ms maximum
Environmental
● Ambient air temperature for operation : 0…40 °C
● Relative humidity : 0…95 % non-condensing
● Operating altitude : 0...3000 m
● Ambient air temperature for storage : -15…45 °C
● Storage Relative Humidity : 0…95 % non-condensing
● Storage altitude : 0…3000 m
● Acoustic level : < 40 dBA
● IP degree of protection : IP20 indoor use only
Communications & Management
● Alarm : Alarm when on battery : distinctive low battery alarm : high temperature : overload continuous tone alarm
● Emergency power off : No
Surge Protection and Filtering
● Surge energy rate : 156 J
Packing Units
● Unit Type of Package 1 : PCE
● Number of Units in Package 1 : 1
● Package 1 Height : 14.2 cm
● Package 1 Width : 10.1 cm
● Package 1 Length : 30 cm
● Package 1 Weight : 4.9 kg
● SCC14 : 10731304769603
Warranty : 2 Years (เสียในประกันยกเข้าศูนย์บริการใกล้บ้าน Advice , JIB. Pace Design หรือ ติดต่อ แจ้งเคลมสินค้า APC ใน QR-CODE)
