Specification
Detail
Specifications
Maximum torque at level I: 0.05Nm
Product colour: Grey
Maximum torque at level II: 0.2Nm
Product dimensions: 201.8 x 74.2 x 25.2mm
Maximum manual torque: 3Nm
Net product weight: 353g
Charging specifications: 5V⎓0.14A
Screwdriver dimensions: 159 x φ16.4mm
Rated voltage: 3.7⎓
Net screwdriver weight: 59g
Lithium battery: 350mAh
Charging time: 160–200min
No-load speed: 170rpm
Screwdriving bit parameters
Screwdriving bit specifications: C4 x 28mm, C4 x 45mm
Screwdriving bit material: S2 steel
Phillips head: PH000/PH00/PH0/PH1
Pentagonal: P2/P5
Hex: H0.7/H0.9/H1.5/H2.0
W Type: W1.5
Slotted: SL1.5/SL2.0
Y Type: Y0.6/Y1
Torx: T2/T3/T4
Tri-wing: 2.3
Torx with pin hole: TH5/T6H/T8H/T9H/T10H
Note: C4 x 45mm for PH0/PH1/SL2.0/T8H/T10H/H2.0, C4 x 28mm for all other types
