Features :
• Programmable Output Voltage to 36 Volts
• Low Dynamic Output Impedance 0.2Ω Typical
• Sink Current Capability of 1.0 to 100mA
• Equivalent Full-Range Temperature Coefficient of 50ppm/°C Typical
• Temperature Compensated For Operation Over Full Rated Operating Temperature Range
• Low Output Noise Voltage
• Fast Turn-on Response
Absolute Maximum Ratings :
• Cathode Voltage (Vka) : 37 V
• Cathode Current Range (Continuous) (Ika) : -100 - +150 mA
• Reference Input Current Range (Iref) : -0.05 - +10 mA
• Power Dissipation (Pd) : 770 mW
