Features
- Light and slim design
- Easy crimping due to optimised transmission ratio
- For crimping wire ferrules according to DIN 46228 parts 1 + 4 from 0.25 to 16 mm²
- Crimping in marked half-round dies for reliable connections between the sleeve and the conductor
- 9 particularly deep dies with conical side faces
Technical attributes
- Part No.: 97 78 180
- EAN: 4003773072003
- Head: polished
- Handles: insulated with multi-component grips, VDE-tested
- Weight: 254 g
- Dimensions: 180 x 54 x 28 mm
- Standard: DIN EN 60900 IEC 60900
- REACH compliant: does not contain SVHC
- RoHS compliant: not applicable
- Application: Wire ferrules
- Capacity in square millimetres: 0.25 — 16.0 mm²
- Number of crimp profiles: 9
- AWG: 24 — 6
- VDE tested: yes
