Run time for load
Min-max: 120-1200 W 1200
W 1m 22s
Max. Capacity Used 100%
Output power capacity 1.2kWatts / 2.2kVA
Nominal Output Voltage 230V
Nominal Input Voltage 230V
Input Connections IEC 60320 C14
Cord Length 1.2meters
Output
Max Configurable Power (Watts) 1.2kWatts / 2.2kVA
Output Frequency (sync to mains) 50/60 Hz +/- 1 Hz Sync to mains
Topology Line interactive
Waveform type Stepped approximation to a sinewave
Transfer Time 6 ms typical : 10 ms maximum
Input
Input frequency 50/60 Hz +/- 5 Hz Auto-sensing
Input voltage range for main operations 140 - 300V
Number of Power Cords 1
Input Power Factor at Full Load 0.54
Batteries & Runtime
Battery type Lead-acid battery
Typical recharge time 8hour(s)
Nominal Battery Voltage 24 V
Expected Battery Life (years) 3 - 5
Battery Volt-Amp-Hour Capacity 216
Physical
Maximum Height 190MM, 19.0CM
Maximum Width 140MM, 14.0CM
Maximum Depth 390MM, 39.0CM
Net Weight 12.3KG
Shipping weight 13.3KG
Shipping Height 297MM, 29.7CM
Shipping Width 235MM, 23.5CM
Shipping Depth 495MM, 49.5CM
Color Black
SCC Codes 10731304410734
