QSW-2104-2T-R2
Management Type Unmanaged
Number of Ports 6
10GbE BASE-T (RJ45) 2
10G/5G/2.5G/1G/100M
2.5GbE (RJ45) 4
Power Supply Description Adapter
Max. Power Consumption 18W
Input Power Type DC
Input Voltage Range 12V/1.5A
MAC Address Table 4K
Total Non-Blocking Throughput 30Gbps
Switching Capacity 60Gbps
Energy Efficient Ethernet (IEEE 802.3az complaint)
Fanless
Supported Standards IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5G/5GBase-T
IEEE 802.3an 10GBASE-T
IEEE 802.3az EEE
IEEE 802.3x Full-Duplex Flow Control
Form Factor Desktop
LED Indicators Per Port: Speed/Link/Activity
Loop LED: Loop
Per System: Power/Status
Dimensions (HxWxD) 26 x 160 x110 mm
Weight (Net) 0.45 kg
Weight (Gross) 0.522 kg
Operating Temperature 0˚C to 40°C (32°F to 104°F)
Relative Humidity 10~95% Non-condensing
Certifications CE, UKCA, FCC, IC, VCCI, RCM, BSMI, LVD, KC
Electromagnetic Compliance CLASS B
Jumbo Frames 12K
Warranty 2 Years
