HARDWARE FEATURES
Interface
• 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Button
• Reset
Power Supply
• 802.3at PoE
• 12 V / 1 A DC
Power Consumption
• EU: 12.8 W (For PoE); 10.8 W (for DC)
• US: 13.9W (For PoE); 11.8 W (for DC)
Dimensions ( W x D x H )
• 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
Antenna Type
Internal Omni
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 5 dBi
Mounting
• Ceiling /Wall Mounting (Kits included)
WIRELESS FEATURES
Wireless Standards
• IEEE 802.11ax/ac/n/g/b/a
Frequency
• 2.4 GHz and 5 GHz
Signal Rate
• 5 GHz: Up to 1201 Mbps
• 2.4 GHz: Up to 574 Mbps
Wireless Functions
• 1024-QAM
• 4× Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO
• Seamless Roaming §
• Omada Mesh§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
Wireless Security
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power
• CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, EIRP)
• FCC:
<25 dBm (2.4 GHz)
<25 dBm (5 GHz)
MANAGEMENT
Omada App
• Yes
Centralized Management
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Cloud Access
• Yes (Through OC300, OC200, or Omada Software Controller)
Email Alerts
• Yes
LED ON/OFF Control
• Yes
Management MAC Access Control
• Yes
SNMP
• v1, v2c, v3
System Logging Local/Remote Syslog
• Local/Remote Syslog
SSH
• Yes
Web-based Management
• HTTP/HTTPS
L3 Management
• Yes
Multi-site Management
• Yes
Management VLAN
• Yes
OTHERS
Certification
• CE, FCC, RoHS
Package Contents
• EAP610
• Power Adapter
• Ceiling/Wall Mounting Kits
• Installation Guide
System Requirements
• Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Environment
• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
Warranty Limited Life Time
